48"x48" Digital Wood Carver commercial CNC machine has a working area of 48" x 48" to accommodate half sheets of plywood. It features our USB CNC Motion Controller Software and Hardware. Vectric CAD/CAM Design Software is Sold Separately. With an 8.0" Z Height, It has 5 T-slots and Vacuum Table, helical rack and pinion in X, Y axis.
Specifications
- Machine with 2.2KW air spindle + 2.2KW 400Hz variable frequency drive, 6000-24000 RPM
- ER25 collet chuck
- Machine size: 1620 x 1610 x 1230 mm ( about 63.7" x 63.4" x 48.4")
- Working size X,Y,Z : 1200 x 1200 x 200mm ( about 48" x 48" x 8.0")
- Resolution: About 0.002"
- X, Y, Z Repeat ability: 0.002"
- Working speed: 200 -500 IPM
- Rapid: 500-800 IPM
- X, Y, Z axis stepper motor driver: High quality stepper motor driver
- X, Y, Z optical switch
- E-stop, Z height probe
- X axis: Helical rack and pinion
- Y axis: Helical rack and pinion with 5:1 gearhead
- Z axis 20m linear rail, 20mm ballscrew
Important Shipping Info
Call for shipping quote. 800.228.0000
