Our 48"x96" Digital Wood Carver Commercial line CNC Machine has a working area of 51.2" x 98.4" to accommodate full sheets of plywood.
The DWC5100 features our USB CNC Motion Controller Software and Hardware. Vectric CAD/CAM Design Software is sold separately. With an 8.0" Z Height, it has 5 T-slots and Vacuum Table, helical rack and pinion in X, Y axis.
Specifications
- X,Y axis working area (51.2" x 98.4")
- Z axis working area ( about 8")
- Max. speed 14m/Min
- Max. working speed 12m/Min
- Working accuracy 0.01mm
- Repositioning accuracy 0.05mm
- Feeding height 120mm
- Working power 4000W
- Working voltage AC220V/50HZ/60HZ
- Spindle power 3.2 KW
- Spindle running speed 0-24000
- Spindle power motor: 3.2KW, Water-cooled, ER20 collet chuck
- Spindle speed: 0-24000 rpm With VFD, AC220V/50Hz/60HZ
- X, Y Z limit switch
- E- stop, Z height probe
- X axis: Rack pinion
- Y axis: Helical rack and pinion with 5:1 gearhead
- Z axis 20m linear rail with 25mm ballscrew
Important Shipping Info
Call for shipping quote. 800.228.0000
